Diaphragm Valve - WLB Series [2-way / Orifice: 2.0 mm / PEEK Body]

$0.00

Variation
Quantity
Inquiry / Quotation

FEATURES / CHARACTERISTICS

pdfpdfView WLB Series [2-way / Orifice: 2.0 mm / PEEK Body] Drawing PDF

The WLB series is a latching solenoid diaphragm isolation valve. Electricity is consumed when energization is only required just an instant opening or closing, so heat generation is very limited. These WLB series pumps have a variety of standard materials that are available for the valve body are PTFE, PEEK, PPS, FKM, and FFKM. Please feel free to contact us for more details of this latching solenoid diaphragm isolation valve, the WLB series.

Note: Details such as specifications, etc. may be changed without notification.

SPECIFICATIONS

Swipe left to see the remaining contents

Model Number WLB-2K
Outer Dimensions W42 x L24 x H51.1 mm
Method Latching Solenoid Diaphragm Isolation Valve
Type 2-way
Port Connection Hose Barb
Orifice（mm） 2.0 mm
IN Port Pressure -90~200 kPa
OUT Port Pressure (NC) 0~100 kPa
Fluid Temperature Range 5~50°C
Ambient Temperature Range 5~50°C
Rated Voltage 12 or 24 VDC
Power Consumption 8 W
Operating Duration Intermittent
Body Material PEEK
Seal Material FKM or FFKM
Other Wetted Materials PTFE
Notes
Model Number Seal Material
WLB-2K-N4F FKM
WLB-2K-N4G FFKM

Note: Details such as specifications, etc. may be changed without notification.
